Rubber Kneader Internal Mixer
Heat Protection Silicone Rubber Heating Belt Production Line – Factory Direct Price Product.
Overview This production line manufactures thermal protection silicone rubber heating belts — a flexible, high-performance heating solution built from nickel-chromium alloy resistance wire encased in insulating silicone rubber.
Engineered for high power density, rapid heat-up, high thermal efficiency, and long service life, the finished belts are ideal for both general constant-power heat tracing and dedicated heating applications.
The silicone rubber heating belt offers excellent waterproof performance, making it suitable for use in humid, non-explosive industrial and laboratory environments — including pipelines, tanks, and vessels. It wraps directly around the surface of the equipment being heated, allowing for fast, simple, and safe installation.
Key Applications
• Hot water pipe insulation, freeze protection, and de-icing/snow-melting in cold-climate regions • Solar water heater pipeline heat tracing
• Heat tracing and insulation for industrial equipment and laboratory pipelines, tanks, and vessels in humid, non-hazardous environments Product Features
• High temperature resistance
• Excellent cold resistance
• Strong aging/weathering resistance • Waterproof and moisture-resistant • High thermal efficiency with fast heat-up • Long operational lifespan • Simple, flexible installation — wraps directly onto pipes/equipment
Production Line Process 1. Rubber Refining — Kneader → Open mixing mill → Batch-off cooler 2. Extrusion — Resistance wire and rubber are co-molded via extruder 3. Cutting & Stripping — Belt is cut to fixed lengths; both ends are stripped by hand or machine to expose the resistance wire 4. Vulcanization — Both ends are vulcanized using a vulcanizing press for a sealed, durable finish
Technical Parameters
| Model |
X(S)N-3x32 |
X(S)N-5x32 |
X(S)N-10x32 |
X(S)N-20x32 |
X(S)N-25x32 |
X(S)N-35x30 |
X(S)N-55x30 |
X(S)N-75x30 |
X(S)N-110x30 |
X(S)N-150x30 |
X(S)N-200x30 |
| Total Volume Of Mixing Chamber (L) |
8 |
15 |
25 |
45 |
55 |
75 |
125 |
170 |
250 |
325 |
440 |
| Working Volume Of Mixing Chamber (L) |
3 |
5 |
10 |
20 |
25 |
35 |
55 |
75 |
110 |
150 |
200 |
| Driving Motor Power (KW) |
5.5 |
11 |
22 |
37 |
37 |
55 |
75 |
110 |
185 |
220 |
280 |
| Tilting Motor Power (KW) |
0.55 |
1.1 |
1.1 |
1.5 |
1.5 |
2.2 |
2.2 |
4 |
5.5 |
11 |
11 |
| Tilting Angle (°) |
140 |
140 |
140 |
140 |
140 |
140 |
140 |
140 |
140 |
135 |
135 |
| Rotating Speed of Rotor Front/Rear (r/min) |
32/24.5 |
32/23.5 |
32/25 |
32/27 |
32/24.5 |
30/24.5 |
32/24.5 |
32/24.5 |
32/24.5 |
30/24.5 |
30/24.5 |
| Pressure of Cooling Water (MPA) |
0.2-0.4 |
0.2-0.4 |
0.2-0.4 |
0.2-0.4 |
0.2-0.4 |
0.3-0.4 |
0.3-0.4 |
0.3-0.4 |
0.3-0.4 |
0.3-0.4 |
0.3-0.4 |
| Overall Dimension LxWxH (mm) |
2000x1000x2220 |
1850x1200x2280 |
2450x1650x2350 |
2675x1650x2560 |
2675x1650x2560 |
3200x1900x2950 |
3230x1927x2958 |
3325x2615x3105 |
4075x2712x3580 |
4250x2750x4106 |
4250x3400x4215 |
| Gross Weight (T) |
~2 |
~2.1 |
~2.1 |
~4 |
~4.5 |
~6.3 |
~7.1 |
~9.5 |
~14.9 |
~19.5 |
~22.5 |
Frequently Asked Questions
What does your factory do regarding quality control?
We implement comprehensive quality control throughout the entire production process. Every machine undergoes full assembly and rigorous testing before shipment to ensure optimal performance.
What's the machine quality guarantee?
We provide a one-year quality guarantee. Our machines incorporate world-renowned brand components to maintain perfect working condition and long-term reliability.
Are you able to provide installation and commissioning overseas? How long will it take?
Yes, we offer overseas installation services and technical support. Installation costs are covered by the customer. Small machines typically require 2-3 days, while larger production lines may take approximately 30 days.
How can I trust you to deliver the right machine as I ordered?
We guarantee delivery of high-quality machines exactly as discussed and confirmed in your order. Our company culture is built on innovation, quality, integrity, and efficiency. We have established successful partnerships with world-renowned rubber production manufacturers and can provide references upon request.
How can we visit your facility?
We are located in Qingdao City, Shandong Province, China. The nearest airport is Qingdao Liuting International Airport. We provide airport pickup services for visiting clients.
Our Services
- Custom machine design with engineering drawings for customer confirmation
- Production progress updates with regular photo documentation
- Complete documentation including packing lists, commercial invoices, and bills of lading
- Complimentary technical documentation: foundation drawings, installation guides, user manuals, maintenance instructions, and part diagrams
- Overseas engineering support and operator training programs
